The Element architectural wall panel system is a horizontally or vertically applied metal panel. Its interlocking legs create a 3/4” or 1” reveal line and concealed clips improve strength and flatness. This durable system combines aesthetic appeal with the quality assurance of IMETCO products in an easy-to-install panel system that is ideal for architectural wall and rainscreen applications.

Product Documents

Design Characteristics

  • Interlocking seams with concealed clips
  • Install over solid substrate with underlayment or over hat sections
  • Features a 1-1/4″ panel depth (varying depths available)
  • Includes a 3/4” or 1″ reveal

Available Materials

  • Aluminum: .050”, .063”, .080”
  • Stainless Steel: 22 and 20-gauge
  • Zinc: 0.8mm and 1.0mm
  • Copper: 16, 20 and 24-ounce

Product Testing

  • AAMA 501.1 (when part of IntelliScreen assembly)
  • AAMA 508 (when part of IntelliScreen assembly)
  • AAMA 509 (when part of IntelliScreen assembly)
  • ASTM E 330
  • ASTM E 283
  • ASTM E 331
