Painted Metals Offer a Wide Array of Color Choices

  Equally as important as the quality and longevity of our metal systems is the creative freedom our products allow. Bring your creativity to life with IMETCO's four painted metals collections. 28 solid colors comprise the Standard, Designer and Premium collections, and six print patterns are featured In the Signature collection.


Custom colors, clear coats, and thick film coatings are available by special order. Color-matched Kynar touch-up paint is also available.

Select an IMETCO color collection below to preview available colors:

To see IMETCO's complete collection, you can download a color chart in .PDF format, or contact us to request a printed color chart or metal color chips.

Standard, Designer and Premium painted finish collections, with Kynar 500® and Hylar 5000® protective coatings, provide outstanding resistance to UV and chemical exposure, and offer unmatched performance and color integrity. The PVF2 or PVDF fluoropolymer coating is applied at 0.70 to 0.90 mils over 0.20 to 0.30 mils of primer to provide a total system dry film thickness of 0.90 to 1.20 mils. The reverse side of the metal is protected by a polyester coating, usually in a white or off-white color, applied over a primer.

Physical Properties of IMETCO PVF2 or PVDF Fluoropolymer Coatings
 Performance Properties  Results: Hot Dipped Galvanized, Galvalume
 Results: Aluminum  Test Designation
 Accelerated Weathering Hours: 1000 Total
Chalk: Rating 8
Color: 5 D E Hunter Units Max
Hours: 1000 Total
Chalk: Rating 8
Color: 5 D E Hunter Units Max
ASTM D 3361
 Salt Spray Hours: 1000 Total
Scribe: Rating 7, 1//16" (2mm)
Field: Rating 10, No Blisters
Hours: 3000 Total
Scribe: Rating 10, No Creepage
Field: Rating 10, No Blisters
ASTM B 117
 Humidity Hours: 2000
Rating 10, No Blisters
Hours: 3000
Rating: 10, No Blisters
ASTM D 2247
 Humidity Hours: 240 Hours
100°F and 100% Humidity
Acceptable**
Hours: 240 Hours
100°F and 100% Humidity
Acceptable**
ASTM D 4585
 Water Immersion Hours: 500 Hours at 100° F
No loss of adhesion
Hours: 500 Hours at 100° F
No loss of adhesion
ASTM D 870
 Formability 2T  2T ASTM D 4145
 Cross Hatch Adhesion No loss of adhesion  No loss of adhesion ASTM D 3359
 Pencil Hardness HB - 2H
HB - 2H ASTM D 3363
 Specular Gloss 10 - 35 @ 60°
10 - 35 @ 60°
ASTM D 523
 Reverse Impact 3X Metal Thickness in inch-lbs
No loss of adhesion
1.5X Metal Thickness in inch-lbs.
No loss of adhesion
ASTM D 2794
 Chemical Resistance Hours: 24, Covered
10% Solutions of Hydrochloric Acid
No Visible Change
Hours: 18, Covered
20% Hydrochloric Acid
No Bleaching
Hours: 18, Covered
20% Sulfuric Acid
No Bleaching
Hours: 1, Covered
25% Sodium Hydroxide
No Color Change, No Blisters
Hours: 15 Minutes , Covered
20% Muriatic Acid
No Color Change, No Blisters
Hours: 24, Covered
10% Solutions of Hydrochloric Acid
No Visible Change
Hours: 18, Covered
20% Hydrochloric Acid
No Bleaching
Hours: 18, Covered
20% Sulfuric Acid
No Bleaching
Hours: 1, Covered
25% Sodium Hydroxide
No Color Change, No Blisters
Hours: 15 Minutes, Covered
20% Muriatic Acid
No Color Change, No Blisters
ASTM D 1308
 Abrasion Resistance (Coefficient)
55 +/- 10 liters of falling sand
55 +/- 10 liters of falling sand
ASTM 968
 Flame Test Class A Coating
Class A Coating ASTM E 84

 * Fluropon is not designed to bridge cracks in the substrate. Due to variability of heavy gauge and hot dipped galvanized metal, some fracturing or rupturing of the substrate is possible with subsequent rupturing of the coatings.

** No less than 5% Number 8 blisters.

*** Meets all requirements of AAMA 2605, including exposure to 10% muriatic acid and nitric acid fumes.

IMETCO® is a registered trademark of Innovative Metals Company, Inc.; United Zinc™ is a trademark of Innovative Metals Company, Inc.; Kynar 500® is a registered trademark of Arkema Inc.; Hylar 5000® is a registered trademark of Solvay Solexis, Inc.; Galvalume® is registered trademark of BIEC International, Inc.; Fluropon® is a registered trademark of the Valspar Corporation.
